DX8370 Multi-functional Vertical Fabric Flammability Tester / Textile Burning Tester
Application Scope:This tester is suitable for testing the flammability of textiles and their components by igniting the edges and bottom edges in the vertical direction. It can also detect the flame retardant performance of sleepwear fabrics, fabric combinations, curtain fabrics and protective clothing fabrics. It complies with multiple domestic and foreign test standards, such as ISO 6940 / ISO 6941
Features:
1. Floor-standing base, no need to place on the workbench, which is convenient for operators to use.
2. Large combustion frame can hang multiple test pin frames to meet the requirements of different test standards.
3. Equipped with 7 types of test pin frames and 1 set of stainless steel sample clamps, satisfying the test standards of various countries.
4. Roller screw adjusts the forward and backward positions of the burner, and the burner height can be finely adjusted through the knob.
5. One-key electric spark ignition mode, which is simple and convenient to operate.
6. Butane or propane combustion gas can be switched programmatically.
7. Flame angle indicator can display the operating angle in real time.
8. The host is equipped with a flame height scale to directly measure the vertical flame height.
Key Specifications:
1. Applicable standards: ISO 6940, ISO 6941
2. Ignition method: One-key electric spark ignition
3. Burner adjustment: The forward/backward position is adjusted by roller screw, and the height is adjusted by knob
4. Accessories configuration: 7 test pin frames + 1 set of stainless steel sample clamps
5. Auxiliary functions: Flame angle indicator, built-in flame height scale
6. Testable samples: Textiles, sleepwear fabrics, curtain fabrics, protective clothing fabrics, etc.
